10km Single Mode Fiber 10G SFP Transceiver Module for Data Center Communication Network Hot Pluggable Compliance SFF-8431

Name: 10km Single Mode Fiber 10G SFP Transceiver Module for Data Center Communication Network Hot Pluggable Compliance SFF8431
Brand: Starsurge
Price: 1 USD

Wholesale 10km Single Mode Fiber 10G SFP Transceiver Module for Data Center Communication Network Hot Pluggable Compliance SFF-8431 from china suppliers

Model Number : CC-PII221L-xD

Place of Origin : China

Brand Name : Starsurge

Price : Negotiable

Certification : RoHS CE FCC UL

MOQ : 1 pc

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 10000pcs/month

Delivery Time : 2-7days

Packaging Details : carton

Type : Optical Transceiver

Use : network

Warranty Time : 1 year

Network : 10G Ethernet

Port : SFP+

Power Source : Low Power Consumption

Connector Type : LC Duplex

Fiber Type : Single Mode Fiber

Encryption : Firmware Encryption

Compliance : SFF-8431

Application : Data Center Communication Network Industrial Automation

EMI Performance : All-metal housing for superior EMI performance

Contact Now

10km Single Mode Fiber 10G SFP Transceiver Module for Data Center Communication Network Hot Pluggable Compliance SFF-8431

10Gb/s 10km SFP+ Optical Transceiver Module CC-PII221L-xD

This 1310nm DFB 10Gbps SFP+ transceiver is designed to transmit and receive optical data over single mode optical fiber for linklength 10km.

The SFP+ 10km module electrical interface is compliant to SFI electrical specifications. The transmitter input and receiver output impedance is 100 Ohms differential. Data lines are internally AC coupled. The module provides differential termination and reduce differential to common mode conversion for quality signal termination and low EMI.

Standards

 IEEE 802.3ae 10GBASE-LR/LW

 SFF-8431

 SFF-8472

Applications

 10GBASE-LR/LW

 Other optical links

Features

 Hot Pluggable

 LC Duplex optical interface

 1310nm DFB transmitter, PIN receiver

 Operating case temperature: Commercial:0 to 70 °C Industrial:-40 to 85 °C

 Low power consumption

 Applicable for 10km SMF connection

 All-metal housing for superior EMI performance

 Advanced firmware allow customer system encryption

 Information to be stored in transceiver

 Cost effective SFP+ solution, enables higher port densities and greater bandwidth

 RoHS compliant (lead free)

Our company is a professional network solution supplier. Based on the information industry, it integrates the research and development of computer network technology and system integration, and provides users with a full range of technical services such as network platforms, system platforms, and application platforms. Show users the solutions of various new network systems and application systems. Our clients cover industries such as government, finance, telecommunications, colleges, transportation,enterprises, hospitals, securities, and public services. The main products include Mellanox, Ruckus,Aruba,Extreme, etc. with favorable prices, rich product catalogs, and perfect after-sales services, the business continues to expand, and customers are all over the United States, South Africa, Europe, East Asia, Russia, and Australia And South America and other countries in the world, has accumulated rich experience in export and customer service. Always to the concept of"quality-oriented, service-oriented", and provide you with cost-effective products and solutions with high-quality professional standards, dedicated attitude and efficient service system. We are committed to building an ecological platform to contribute to the development of information technology!

Q1.What can you buy from us?

Mellanox, Aruba, Rukus, starsurge,Extreme brand products, including switches, network cards, cables, modules, AccessPoint, etc.
Q2.How about the delivery date?
It usually takes 3-5 working days. For specific models, please contact us to check thestock. In the end, the actual consultation shall prevail. We will do our best to deliver as soon as possible.
Q3.What's yourwarranty terms?
We supply 12 months warranty time.
Q4.How about the Shipping Method?
We use Fedex/DHL/UPS/TNT and other air shipments,sea shipments are also workable. In one words, we could do any shipments that you wanted.
Q5.Can I get some samples?
Yes, sample order is available for quality check and market test. You only need to pay the sample cost and express cost.
Q6.What are your core strengths?
First-hand supply, Original and new products with the favorable price and perfect after-sales service.
Q7.Price questions
The inventory turnover is fast, and the cost of each batch of goods fluctuates according to the market price. The final price is subject to the sales quotation. Please understand.

10km Single Mode Fiber 10G SFP Transceiver Module for Data Center Communication Network Hot Pluggable Compliance SFF-8431 Images
