MFS1S00-H005V Aoc Active Optical Cable Up To 200Gb/S IB HDR QSFP56 5m

Product Categories
Hong Kong Starsurge Group Co., Limited
Contact Now

MFS1S00-H005V Aoc Active Optical Cable Up To 200Gb/S IB HDR QSFP56 5m

  • 1
  • 2

Brand Name : Mellanox

Model Number : MFS1S00-H005V

MOQ : 1pcs

Price : Negotiable

Payment Terms : T/T, Western Union, MoneyGram Xtransfer

Supply Ability : 10000pcs/month

Delivery Time : 7-10days

Packaging Details : carton

Availability : stock

Warranty : 1 Year

condition : new and original

Technology : InfiniBand

type : mellanox AOC cable

Cable Length : 5 meters

model : MFS1S00-H005V

name : MFS1S00-H005V Aoc Active Optical Cable Up To 200Gb/S IB HDR QSFP56 5m

keyword : mellanox cable

Contact Now

Mellanox AOC cable MFS1S00-H005V active optical cable up to 200Gb/s IB HDR QSFP56 5m

MFS1S00-H005V mellanox AOC cable Product Description

MFS1S00-H005V is a QSFP56 VCSEL-based (Vertical Cavity Surface-Emitting Laser) active optical cable (AOC) designed for use in 200Gb/s InfiniBand HDR systems. The MFS1S00-HxxxE AOC offers high port density and configurability, and a much longer reach than passive copper cables in the data centers. Since the AOC is hot pluggable, it is easy to install and replace.MFS1S00-H005V has a standard SFF-8665 compliant QSFP56 port on the electrical side towards the host system. It contains four multi-mode fibers (MMF) optic transceivers per end; each operating at data rates of up to 50Gb/s.

Highlights

  • 200GbE data rate
  • 4x 50Gb/s PAM4 modulation
  • Programmable Rx output amplitude and pre-emphasis
  • SFF-8665 compliant QSFP56 port
  • Single 3.3V power supply
  • 4.35W power dissipation (typ., each end with retiming)
  • Enables BER (Bit Error Rate) better than 1E-15
  • Up to 100m length
  • Hot pluggable
  • RoHS compliant
  • SFF-8636 compliant I2C management interface


MFS1S00-H005V mellanox AOC cable parameter form

Item features
Name MFS1S00-H005V mellanox AOV cable
Cable Type Active Optical Cable
Cable Length 5 meters
Data Rate Up to 200Gbps
Connector Type QSFP56
Supported Protocols InfiniBand EDR, HDR, and NDR; Ethernet 100GbE and 25GbE
Power Consumption < 1.5W per cable
Operating Temperature 0°C to 70°C
Technology InfiniBand
condition new and original

MFS1S00-H005V Aoc Active Optical Cable Up To 200Gb/S IB HDR QSFP56 5m

MFS1S00-H005V Aoc Active Optical Cable Up To 200Gb/S IB HDR QSFP56 5m

MFS1S00-H005V Aoc Active Optical Cable Up To 200Gb/S IB HDR QSFP56 5m

MFS1S00-H005V Aoc Active Optical Cable Up To 200Gb/S IB HDR QSFP56 5m

model description
MFS1S00-H005V Mellanox AOC DAC cable 200Gb 100Gb 25Gb 40Gb 5M 10M 15M 20M 30M QSFP28 QSFP56
MFS1S00-H005V mellanox breakout cable 200Gb 100Gb 25Gb 40Gb 5M 10M 15M 20M 30M QSFP28 QSFP56
MFS1S00-H005V mellanox passive copper cable 200Gb 100Gb 25Gb 40Gb 5M 10M 15M 20M 30M QSFP28 QSFP56
MFS1S00-H005V mellanox infiniband cables 200Gb 100Gb 25Gb 40Gb 5M 10M 15M 20M 30M QSFP28 QSFP56
MFS1S00-H005V console cable 200Gb 100Gb 25Gb 40Gb 5M 10M 15M 20M 30M QSFP28 QSFP56
MFS1S00-H005V active fiber cable 200Gb 100Gb 25Gb 40Gb 5M 10M 15M 20M 30M QSFP28 QSFP56
MFS1S00-H005V hdr cables 200Gb 100Gb 25Gb 40Gb 5M 10M 15M 20M 30M QSFP28 QSFP56
MFS1S00-H005V mellanox splitter cable 200Gb 100Gb 25Gb 40Gb 5M 10M 15M 20M 30M QSFP28 QSFP56
MFS1S00-H005V mellanox edr cables 200Gb 100Gb 25Gb 40Gb 5M 10M 15M 20M 30M QSFP28 QSFP56
MFS1S00-H005V high-speed interconnect cable 200Gb 100Gb 25Gb 40Gb 5M 10M 15M 20M 30M QSFP28 QSFP56
MFS1S00-H005V fast interconnect cable 200Gb 100Gb 25Gb 40Gb 5M 10M 15M 20M 30M QSFP28 QSFP56
MFS1S00-H005V Ethernet cable 200Gb 100Gb 25Gb 40Gb 5M 10M 15M 20M 30 QSFP28 QSFP56
MFS1S00-H005V InfiniBand cable 200Gb 100Gb 25Gb 40Gb 5M 10M 15M 20M 30M QSFP28 QSFP56
MFS1S00-H005V hdr cables 200Gb 100Gb 25Gb 40Gb 5M 10M 15M 20M 30M QSFP28 QSFP56

Company
Starsurge Group Co. is a new technology enterprise dedicated to IT network system integration and application software product research and development. Since its establishment, relying on rich industry experience and understanding of customer business, it has continuously developed and innovated, and provided professional technical services for customers in various industries such as government and enterprise, medical care, manufacturing, and the Internet to achieve digital transformation.
We have the overall comprehensive strength of software development, design implementation, and consulting services. The company has cultivated an excellent technical research and development, management, marketing and service team.
