RUCKUS ICX 8200-24F Enterprise Stackable Fiber Access Switch
1. Product Overview
The RUCKUS ICX 8200-24F is an enterprise-class stackable fiber access switch designed for high-performance and scalable network deployments. It features 24x 1GbE SFP fiber ports and 4x 1/10/25 GbE SFP28 uplink/stacking ports, making it ideal for bandwidth-intensive environments. This switch supports advanced Layer 2 and Layer 3 features, VXLAN for network segmentation, and offers flexible management options including cloud, on-premises, and controllerless modes.
2. Key Features
- 24x 1GbE SFP fiber ports for high-density fiber connectivity
- 4x 1/10/25 GbE SFP28 uplink/stacking ports
- VXLAN support for enhanced security and network segmentation
- Advanced Layer 3 routing (static, RIP, OSPF, VRRP, VRF, GRE, PIM, PBR)
- Unified management via RUCKUS SmartZone, Cloud, or Unleashed
- Stackable up to 12 units with 10km stacking distance
- Energy Efficient Ethernet (802.3az)
3. Technology
The ICX 8200-24F leverages cutting-edge technologies including VXLAN for secure network segmentation, Multigigabit Ethernet support, PoE/PoE+/PoE++ compliance, and advanced Layer 3 routing protocols. It also supports OpenFlow for SDN integration and offers high availability features such as hitless failover and in-service software updates.
4. Working Principle
The switch operates at the network edge, aggregating traffic from multiple devices and forwarding data based on MAC and IP addresses. It uses hardware-based forwarding engines to ensure low latency and high throughput. The stacking functionality allows multiple switches to operate as a single logical unit, simplifying management and increasing resiliency.
5. Applications
Ideal for enterprise campuses, data centers, educational institutions, healthcare networks, and large-scale wireless deployments. The ICX 8200-24F is particularly suited for environments requiring high-speed fiber connectivity, such as backbone networks, server farms, and aggregation layers supporting Wi-Fi 6/6E/7 Access Points.
6. Specifications
| Attribute | Value |
| Ports | 24x 1GbE SFP, 4x 1/10/25GbE SFP28 |
| Switching Capacity | 248 Gbps |
| Forwarding Rate | 184 Mpps |
| Power Consumption | 65W (10% traffic, no PoE) |
| Dimensions (HxWxD) | 4.4cm x 44cm x 28cm |
| Weight | 3.77 kg |
| MTBF | 1,190,512 hours |
7. Advantages
- Future-proof design with 25GbE uplinks and stacking
- High availability with redundant power and fan options
- Comprehensive security features including ACLs, 802.1X, and MAC security
- Flexible management and SDN support
- Low latency and high throughput for real-time applications
8. Service & Support
All RUCKUS ICX 8200 switches come with a limited lifetime warranty and 3 years of remote TAC support. Next-business-day advanced replacement is available in eligible regions. Additional on-site and extended support options can be purchased.
9. FAQ
Q: What is the maximum stacking distance?
A: Up to 10 km between stacked switches.
Q: Does it support PoE?
A: The ICX 8200-24F is a fiber switch and does not support PoE.
Q: Can it be managed via the cloud?
A: Yes, via RUCKUS Cloud, SmartZone, or Unleashed.
Q: What Layer 3 protocols are supported?
A: Static, RIP, OSPF, VRRP, VRF, GRE, PIM, and PBR (with license).
Q: Is it compatible with Wi-Fi 6/6E Access Points?
A: Yes, it is optimized for high-density wireless deployments.
10. Precautions
- Ensure compatible SFP/SFP+ modules are used.
- Operate within specified temperature (0°C to 45°C) and humidity (10% to 90%) ranges.
- Follow local electrical and safety regulations during installation.
- Verify firmware compatibility before upgrading.
- Use approved power cords and accessories.
